Metalkraft Precision Surface Grinding Machine | MK3933060
R 862,499.00 ZAR
R 862,499.00 ZAR
VAT included.

FSM 3060

Precision surface grinding machine

Technical Specifications

Size of the clamping plate 300 x 600 mm
Max. Distance between spindle and table 500 mm
Traversing speed of the table 5 - 25 m / min
Max. Workpiece weight 215 kg
Spindle speed 1450 min-1
Size of the grinding wheel 355 x 38 x 127 mm
Motor power spindle 3.75 kW
Engine power hydraulic pump 0.75 kW
Electrical connection 400 V / 50 Hz
Dimensions (L x W x H) 2650 x 1550 x 1800 mm
mass 1700 kg

description

FSM - precision surface grinding machines with NC-controlled vertical feed

  • For precision surface grinding in the industrial sector
  • Maximum rigidity and stability thanks to stress-free re-hardened and hardened cast iron construction
  • IP65-protected halogen lighting
  • With automatic central lubrication for all slides and spindles
  • Electromagnetic clamping plate for fixing the workpiece incl. Automatic demagnetization function
  • High quality spindle with precision tapered roller bearings (concentricity 2 μm)
  • Hand-scraped and "Turcite-B" coated V-flat guides guarantee extremely smooth, low-friction movement and maximum precision
  • Second grinding wheel flange

Delivery Information

  • Electro-magnetic chuck
  • automatic demagnetizer
  • Grinding wheel
  • grinding wheel
  • Balancing arbor
  • parallel wheel
  • Ausrichtfüße
  • operating tool
  • Halogen work light (IP65)
  • Coolant system
