Metalworking for the Woodworker: Expand Your Toolbox (Literally)

When you’re planning your next woodworking project, sometimes the hardware options just don’t cut it. What if you could mix in your own metal accents — custom drawer pulls, brackets, inlays, or reinforcing struts — to elevate the look and structure? With a few basic techniques, you can bring metalworking into your woodworking shop and open up a host of creative possibilities.

In this post, I’ll walk you through what you need to know to combine metal with wood — from choosing materials to cutting, shaping, joining, and safety—without burying you in technical jargon.

Know Your Metals: Ferrous vs. Nonferrous

Before you begin, you need to know what kind of metal you're working with. In broad strokes:

• Ferrous metals contain iron — e.g. many steels. These are magnetic.


• Nonferrous metals do not contain iron — e.g. aluminum, brass, copper. These are generally more forgiving to machine with woodworking tools.



A simple magnet test will tell you which side you’re on: if the piece is attracted, it’s likely ferrous; if not, you’re working with a nonferrous metal.

Aluminum, brass, and thin sheet materials are easier to handle with tools you may already own. Steel, especially in heavier gauges, demands more purpose-built blades and care.

Tooling & Shop Setup

You won’t necessarily need a full metal shop, but some adjustments to your woodworking setup help immensely:

• Cutting tools: A dedicated metal chop saw is ideal — its carbide blade is designed for cutting steel cleanly (with minimal heat or sparks). For lighter metals, your mitersaw can pull double duty if fitted with a blade designed for nonferrous metals.


• Bandsaw: With a fine-toothed blade (3–4 TPI), you can cut brass, aluminum, and other soft metals—even curves or odd shapes.


• Snips & files: For sheet metal, tools like left-, right-, and straight-cut snips can make short work out of thinner material. Use a bastard mill file for smoothing edges.


• Jigsaw: Fitted with a 24 TPI bi-metal blade for thin metals (or 12–18 TPI for heavier stock), a jigsaw can be surprisingly effective — just go slow and steady.


• Bending tools: A bending brake helps you get clean bends in sheet metal. You can build a simple one with a hinged plywood assembly. To bend heavier steel, heat it with a torch and use locking pliers to shape it safely.


• Drilling & tapping: Metal requires a solid hold while drilling. Use clamps or a v-groove in a scrap backing piece. Match drill-press speed to the bit size, and always use cutting oil. Once your hole is drilled, use a tap handle (or drill-press start) to cut internal threads. Go slowly, back out to clear chips, and keep everything aligned.


• Riveting & fastening: For permanent metal-to-metal or metal-to-wood connections, rivets are a good choice. Drill matching holes, insert the rivet, and use a riveter to set the joint. Of course, machine screws and bolts offer more flexibility if your design may evolve or need disassembly.



One key tip: dedicate a separate area (or a sacrificial surface) for metalwork tasks. Metal chips, grinding sparks, and sharp edges can wreak havoc on wood surfaces if they mingle.

Safety First

Safety is non-negotiable when combining metal and wood in the shop. Some essential precautions:

• Wear safety glasses (or a face shield) and hearing protection.


• Use a heavy leather apron and gloves when grinding or shaping metal.


• Secure your workpiece with clamps or vises before cutting, drilling, or grinding.


• Keep sparks, swarf (metal shavings), and combustible materials far apart. Always check for smoldering debris before leaving the shop.


• Work methodically — if something feels unsafe or awkward, pause and rethink your approach.



Bringing It Together: Ideas & Applications

Once you’re comfortable with basic metalworking techniques, the creative payoff is huge. Here are a few ideas to incorporate metal into your woodworking:

• Custom hardware: Create your own drawer pulls, hinges, or brackets to match your design vision exactly.


• Reinforcement & structure: Add steel brackets or aluminum plates in hidden or exposed areas to improve strength and durability.


• Decorative inlays: Use brass or copper inlays or bowtie shapes embedded in wood surfaces to add contrast and visual interest.


• Metal edges and trim: Accent a tabletop or casework edge with aluminum or brass edging for a sleek, modern detail.



The beauty of blending metal with wood is that you're no longer limited to what’s commercially available. Your projects become more personal, expressive, and structurally capable.

Metalworking may sound intimidating if you’re coming from a purely woodworking background, but with patience and the right tools, it’s surprisingly accessible. Understanding your materials, adapting your tools, prioritizing safety, and practicing basic cuts, bends, drills, and joins will unlock a broader design horizon.

Start small — try adding a metal accent or bracket — and gradually expand. Over time you’ll gain confidence in shaping both wood and metal in harmony. The next time you plan a project, don’t just think “wood-only” — think “wood + metal” and see what new possibilities emerge.
