► No wearing parts (carbon brushes, commutator, field coil)
► Our original compact controller
The brushless motor offers a significantly extended product life cycle by eliminating trouble including armature burnout, layer short or commutator wear even in severe work environments. Besides, no carbon brush replacement is required.
Equipped with our original, compact high efficiency inverter circuit, the demolition hammer works with an engine generator that doesn't have an on-board inverter.
The brushless motor runs cooler, and its performance isn't affected as much by voltage drop from long extension cords on site. This vastly improves electrical efficiency.
The highly efficient AC brushless motor provides stable performance during voltage drops, delivering the best in class performance with an extension cord, up to 1.2 x more*2 compared to our previous model.
reduces the vibration from demolition by moving a weight and leaf spring in the opposite direction to the movement of the hammer.
Our original vibration-absorbing mechanism with the Transatory unit (rubber dampers) and the hinge unit provides high vibration absorbing effect. This will help absorb and reduce vibrations to the user, making it more comfortable for prolonged periods of time.
makes the housing more rigid, and significantly enhances durability of the motor unit.
(1) Push-button, constant speed control with variable speed
The built-in electronic control circuit adjusts the impact rate according to applications, and the four-step impact rates can be selected by the impact rate selector switch.
| Display Lamp |  |
 |
 |
 |
| Full Load Impact Rate |
1,500/min | 1,700/min | 1,900/min | 2,100/min |
|---|
(2) Power Lamp
lights up when the plug is inserted into an outlet.
A bit can be mounted by simply inserting it into the tool holder
The change lever allows for easy mode switching between neutral (for bit angle adjustment) and hammering (for demolition). The tool bit angle can be adjusted to 12 different angles every 30 degrees by turning the grip.
Large easy-to-grip trigger switch for more control.
