Makita 18V Cordless Brushless 1/2" Square Drive Impact Wrench 700Nm (Bare Tool) | DTW700ZJ.
The Makita 18V Cordless Brushless 1/2" Square Drive Impact Wrench combines high torque output with a compact and ergonomic design, making it suitable for demanding fastening applications. Powered by Makita’s 18V LXT Li-Ion battery platform, it delivers up to 700 N·m (520 ft.lbs.) of fastening torque and an impressive 1,000 N·m (740 ft.lbs.) of nut-busting torque, ensuring reliable performance when working with stubborn fasteners.
Furthermore, the brushless motor enhances efficiency by electronically optimising energy usage, which extends runtime while maintaining consistent performance. As a result, the motor runs cooler and eliminates carbon brushes, thereby improving durability and service life. In addition, the variable 4-speed control allows users to adjust torque and speed according to the application, providing greater precision and control.
The tool features a compact body with an overall length of just 170 mm (6-11/16"), which makes it easier to operate in confined spaces. At the same time, the ergonomically designed soft grip handle improves comfort, while the trigger switch with full speed mode reduces hand and finger fatigue during prolonged use.
Moreover, three modes of reaction time for automatic stop are available in both forward and reverse rotation, enhancing fastening control. Twin LED lights with pre-glow and afterglow functions improve visibility in low-light conditions, while the electric brake increases operator safety. The durable belt clip allows for convenient temporary hanging, and the reverse switch is positioned for easy access.
Additionally, the tool features Makita’s Extreme Protection Technology (XPT) for improved water resistance, along with a battery protection circuit that protects against overloading, over-discharging, and overheating, ensuring reliable operation in demanding environments.
Features & Benefits:
-
High Torque Performance: Delivers up to 700 N·m (520 ft.lbs.) fastening torque and 1,000 N·m (740 ft.lbs.) nut-busting torque for demanding applications.
-
Brushless Motor: Improves efficiency, reduces heat build-up, and extends motor life by eliminating carbon brushes.
-
Variable 4-Speed Control: Enables precise adjustment of speed and torque for different fastening requirements.
-
Compact Design: Short overall length of 170 mm (6-11/16") allows easy access in tight spaces.
-
Automatic Stop Function: Three selectable reaction time modes improve control in forward and reverse rotation.
-
Ergonomic Soft Grip Handle: Enhances comfort and reduces fatigue during extended use.
-
Full Speed Trigger Switch: Minimises hand and finger strain while maintaining performance.
-
Twin LED Lights: Provides improved illumination with pre-glow and afterglow functions.
-
Electric Brake: Increases safety by stopping the tool quickly after release.
-
1/2" (12.7 mm) Square Drive: Allows quick socket changes with secure C-ring fixing.
-
XPT Protection: Improves resistance to water for increased durability in tough conditions.
-
Battery Protection Circuit: Protects against overload, over-discharge, and overheating.
-
Durable Belt Clip: Provides convenient temporary storage on-site.
Specifications:
-
Code: DTW700ZJ
-
Shank / Drive: Square Drive 12.7 mm (1/2")
-
Max Fastening Torque: 700 N·m (520 ft.lbs.)
-
Nut-Busting Torque: 1,000 N·m (740 ft.lbs.)
-
Fastening Capacity (Standard Bolt): M10 – M24 (3/8" – 1")
-
Fastening Capacity (High Strength Bolt Grade 10.9): M10 – M16 (3/8" – 5/8")
-
Fastening Capacity (High Strength Bolt Grade F10T): M12, M16 (7/16", 5/8")
-
No Load Speed (Max / Hard / Med. / Soft): 0 – 2,200 / 0 – 1,900 / 0 – 1,200 / 0 – 500 min⁻¹
-
Impacts Per Minute (Max / Hard / Med. / Soft): 0 – 2,700 / 0 – 2,400 / 0 – 1,700 / 0 – 1,000 min⁻¹
-
Max Output: 430 W
-
Vibration Level: 19.0 m/s²
-
Vibration K Factor: 2.0 m/s²
-
Sound Pressure Level: 94 dB(A)
-
Sound Power Level: 105 dB(A)
-
Noise K Factor: 3 dB(A)
-
Dimensions (L × W × H): 170 x 81 x 276 mm (6-11/16 x 3-3/16 x 10-7/8")
-
Net Weight: 2.3 – 2.7 kg (5.1 – 6.0 lbs.)
Scope of Delivery:
- 1 x Makita 18V Cordless Brushless 1/2" Square Drive Impact Wrench (Bare Tool)
Please Note: Kindly be aware that the images serve solely for illustrative purposes; the items included in the delivery are specified in the product content/description or as indicated by the product title.
