High Power Output:
Boasting a remarkable 1000W output power, this system ensures an abundant and consistent power supply for various devices.
Long-Lasting Battery:
The LiFePo4 battery with a cycle life of over 2000 charge cycles offers exceptional durability and reliability.
Versatile Charging:
Charge via mains electricity, your car, or optional solar panels, offering flexibility and convenience.
Safe and Stable:
The upgraded Lithium Iron Phosphate battery enhances thermal and chemical stability, ensuring safety and preventing fire hazards.
Multi-Output Options:
AC, DC, and USB outputs allow you to power a wide range of electronic devices effortlessly.
Weather-Resistant Design:
With an IP-65 waterproof casing, this system thrives even in challenging outdoor conditions.
Wide Temperature Range:
Its operational temperature range of -20°C to 65°C guarantees performance in diverse environments.
Smart Protections:
Benefit from safety features such as over-charge, over-discharge, temperature, and overload protections.
Optimize Solar Charging:
If utilizing solar panels, position them to receive maximum sunlight exposure for efficient charging.
Battery Maintenance:
Periodically check battery health and ensure it's not fully discharged for prolonged periods to extend its lifespan.
Load Management:
Distribute power usage evenly across outputs and avoid exceeding the system's rated capacity to avoid overloading.
Temperature Awareness:
Keep the system within its specified temperature range for optimal performance and longevity.
Emergency Preparedness:
Keep the Switched ESS Solar Power System fully charged to have a reliable backup during power outages.
- Rated power -1000W
- Output voltage waveform -Pure sine wave
- Output voltage regulation - 230Vac±5%
- Output frequency -50Hz or 60Hz
- Peak efficiency -90%
- Nominal DC input voltage -12Vdc (±0.3)
- Standby Consumption - < 25W
- Max solar power input -900W
- PV max charging current -60A (±3A)
- Combined charging current -70A (±4A)
- Max efficiency -98.0% max
- PV array open circuit voltage -105VDC
- PV Array MPPT Voltage Range -15~105V
- AC input voltage -230Vac ±5%
- Acceptable input voltage range -90-280VAC
- Nominal input frequency -50Hz / 60Hz (Auto detection)
- Transfer time -10ms typical (UPS, VDE); 20ms typical (APL)
- Charging current at Nominal input voltage -10/20A (±4A)
- Charging Algorithm - 4-step (Li)
- AC output -230Vac (Socket x 4pcs)
- USB (5V 2.4A) -DC output x 2pcs
- USB (12V 1A) -DC output x 1pcs
- Nominal voltage 12.8V
- Battery capacity -1280Wh
- Protection board -100A
- Standard charging and discharge current -50A
- Maximum charging & discharge current -100A
- Operation ambient temperature -Charge-0~45℃
- Discharge -10~60℃
