Portable Powerhouse:
This inverter offers a continuous 2400W output, converting 24V DC battery power into 120V AC power, making it suitable for a wide range of applications.
Peak Performance:
With peak surge outputs of up to 3600W in OverPower mode and 4800W in Double-Boost mode, it can handle high-power demands with ease.
Multiple Outlets:
Equipped with NEMA 5-15/20R outlets, the inverter allows you to connect multiple devices simultaneously.
Stability and Control:
Frequency control ensures stable operation and prevents disruptions in power delivery.
Dual Fuel Capability:
Enjoy the flexibility of using either gasoline or propane as a fuel source, making it ideal for various outdoor activities.
Tips for Using the Product
Battery Connection:
Ensure secure bolt-down connections to the 24V battery terminals for optimal performance.
Load Management:
Prioritize your power needs by understanding the wattage requirements of your devices before connecting them.
Regular Maintenance:
Keep the inverter clean and inspect connections regularly to prolong its lifespan.
- Pure sine ware output - 240V L1-L2
- Optional MPPT/PWM solar charge controller 60A/80A/100A/120A
- MPPT Efficiency max 98%
- DC Start & Automatic Self-Diagnostic Function
- High Efficiency Design & ”Power Saving Mode” to Conserve Energy
- Auto restart when AC is recovering
- Smart battery charger design for optimized battery performance
- Selectable charging current based on applications
- AC input/DC input/Solar input optional priority
- Auto Restart Voltage
- Capacity(VA) 3000VA
- Rated Power 2400W
- Voltage(DC)12V/24V/48V
- Input Voltage 220VAC
- Voltage Range 154-265VAC ;185-264VAC ( selectable)
- Frequency 50-60HZ Auto-sensing
- Power Factor 0.8
- Output Voltage 220VAC±10%
- Frequency 50/60Hz±5%
- Waveform Pure Sine Wave
- Output Voltage Regulation 土10%
- Bypass Mode Yes
- Saver Mode Yes
- Efficiency Circuit Breaker
- Input Protection Circuit Breaker
- Output Protection VRLA / GEL /GEL DEEP CYCLE/Lithium
- Charging Current 30A/15A
- Battery Charging Voltage13.5VDC/27VDC/54VDC
- Maximum PV Array Power 24V: MPPT 30V-150VDC / PWM 30V-60VDC 48V: MPPT 60V-150VDC / PWM 60V-105VDC
- Maximum solar charge current 60A
- LCD indicator status AC input voltage/input frequency, PV voltage, PV current, Output Voltage/Frequency, Battery voltage, Load current etc.
- LED indicator status AC Line In Green/Inverter: Red/Charging: Yellow/Alarm: Red
- LOW battery alarm Audible alarm-5 seconds beeping
- Overload alarm Audible alarm- continuous beeping
- Fault 0-60℃
- Temperature —10℃~90℃ Non-condensing
- Size L*W*H(mm) 470mmX335mmX210mm
- Weight (kg) 20
