High-Powered Energy:
Experience a robust power output of 5200W, ensuring an uninterrupted energy supply for your devices and appliances.
Advanced LiFePo4 Battery:
Built with lithium iron phosphate technology, the battery provides exceptional durability, long cycle life, and enhanced safety.
Portable Trolley Design:
The integrated trolley design allows effortless mobility, making it easy to transport the power station wherever power is needed.
Versatile Charging Options:
Charge the unit through solar panels, AC outlets, or car chargers, granting you multiple ways to keep it powered up.
Multiple Output Ports:
The power station features a variety of output ports including AC, DC, and USB, catering to a wide range of devices simultaneously.
Intelligent Display:
Monitor battery status, input/output power, and more with the intuitive built-in display.
Emergency Backup:
Be prepared for power outages with this reliable backup solution that ensures essential devices stay operational.
Efficient Cooling System:
The power station incorporates an efficient cooling mechanism to prevent overheating during extended use.
- Rated power -5200W
- Output voltage waveform -Pure sine wave
- Output voltage regulation -230Vac±5%
- Output frequency -50Hz or 60Hz
- Peak efficiency -93%
- Nominal DC input voltage -48Vdc
- Standby Consumption - < 25W
- Max solar power input -6000W
- PV max charging current -80A
- Combined charging current -80A
- Max efficiency -98.0% max
- PV array open circuit voltage -450VDC
- PV Array MPPT Voltage Range -150V-430VDC
- AC input voltage -230Vac ±5%
- Acceptable input voltage range -170~280VAC
- Nominal input frequency -50Hz / 60Hz (Auto detection)
- Transfer time -10ms typical (UPS, VDE); 20ms typical (APL)
- Charging current at Nominal input voltage -60A
- Charging Algorithm 4-step (Li)
- AC output -230Vac (Terminal)
- Nominal voltage - 51.2V
- Battery capacity - 5120Wh
- Standard charging and discharge current -100A
- Maximum charging & discharge current -100A
- Operation ambient temperature -Charge-0~45℃
- Discharge -20~55℃
Tips for Using the Product
Optimal Placement:
Place the power station in a well-ventilated area to ensure efficient cooling and prolong battery life.
Regular Maintenance:
Periodically charge and discharge the battery to maintain its capacity and prolong its overall lifespan.
Load Management:
Distribute power usage across various outputs to prevent overloading and optimize performance.
Solar Charging:
Take advantage of solar panels to recharge the power station while on outdoor excursions.
Safe Storage:
When not in use, store the power station in a cool, dry place to preserve its condition.
